SM4T4DPA

Managed Layer 2 Gigabit Ethernet Switch
(4) 10/100/1000Base-T Ports + (4) 100/1000Base-X SFP Slots

Product Brief Request a Demo

This switch is a high performance Layer 2 managed switch with (4) 10/100/1000Base-T copper ports and (4) dual speed 100/1000Base-X SFP slots.

SM4T4DPA Overview

Features

Supports Jumbo Frame up to 9K bytes
Authentication – RADIUS IEEE 802.1X, TACACS+
Security – Supports SSH/SSL
Port based or tagged (IEEE 802.1Q) VLAN, QinQ double tag VLAN, Guest VLAN
Bandwidth Allocation Ingress and Egress
DHCP Snooping including option 82
IP-MAC binding for security
ACL based on Ethernet Type / ARP / IPv4 for packets permit or deny, ratelimitation and port copy
LLDP (Link Layer Discovery Protocol)
SYSLOG for device management
IEEE 802.3az Energy Efficiency
Single IP management
Web Management, SNMP V1/V2c/V3, Telnet, CLI
Supports IEEE 802.3ad port trunk with link aggregation control protocol (LACP)
Support IGMP Snooping V1/V2/V3, IGMP Proxy and GVRP
Supports 8 hardware queues with Strict priority and WRR. Per port bandwidth management
Supports IEEE 802.1s MSTP, IEEE 802.1w RSTP and IEEE 802.1D STP Compliant
Port Based VLAN, IEEE 802.1Q tag based, 4096 VLAN entries, MAC-based VLAN, Private VLAN Edge, Priority VLAN override
Firmware Update, configure backup/ restore through Web GUI and TFTP
Support IPv4/IPv6 dual protocol stack
Redundant Ring Protection Protocol

SM4T4DPA Tech Specs

Standards

IEEE 802.3
IEEE 802.3u
IEEE 802.3z
IEEE 802.3x
IEEE 802.3ad
IEEE 802.1D
IEEE 802.1w
IEEE 802.1X
IEEE 802.1s
IEEE 802.1Q
IEEE 802.1p
IEEE 802.1ad
IEEE 802.1AB
IEEE 802.3az

Connectors

(1) RJ-45 console port
(4) 10/100/1000 RJ-45 ports
(4) 100/1000 SFP slots

Protocols

CSMA/CD

Technology

Store-and-Forward switching architecture

MAC Address

8K MAC address table

Backplane

16 Gbps

Dimensions

Width: 8.66” [220 mm]
Depth: 6.26” [159 mm]
Height: 1.69” [44 mm]

Power Input

Internal power: 100-240VAC

Environment

Operating: 0°C to 40°C
Humidity: 5% to 90% (non-condensing)

Weight

3.85 lbs. [1.75 kg]

Certifications

Safety: LVD
Emissions: FCC Class A, CE

Warranty

5 Years

Warranty

5 Years

SM4T4DPA Downloads

Additional Product Information

Note: Some Documentation may have Transition Networks named or pictured. Transition Networks was acquired by Lantronix in August 2021. Learn more about the acquisition here.

Certificates

Don’t see the certificate you need? Contact us to explore options and timelines for new certificates.

CERT DOC UKCA SM4T4DPA

DofC

208 KB

View

Product Information

SM4T4DPA Datasheet (PDF 210.98 KB)

211 KB

View

User Guides

SM4T4DPA CLI User Guide

SM4T4DPA Installation Guide

951 KB

View

Visio Stencils

Plan your network with Microsoft Visio Stencils. You must log in or create a MyLantronix account to access Visio Stencils.

Firmware Downloads

Keep your products up to date by downloading the latest firmware. You must log in or create a MyLantronix account to download firmware.

SM4T4DPA Part Numbers

Lantronix Part #	Name	Description	Order Now
Sorry, no parts were found that match that search query.

Lantronix Part # SM4T4DPA	Name SM4T4DPA	(4) 10/100/1000Base-T ports + (4) 100/1000Base-X SFP slots	Contact Us
Compatible Accessories
Lantronix Part # SFP Modules	Name SFP Modules		Contact Us
Lantronix Part # BRSM8-01	Name BRSM8-01	Wall Mount Bracket for SM4T4DPA	Contact Us
Lantronix Part # RMSM4-01	Name RMSM4-01	19″ Rack Mount Bracket for SM4T4DPA	Contact Us
